介绍：

LAYERTEC公司于1990年成立于德国，是世界的光学镜片OME厂。凭借多年在光学领域中对飞秒激光镜片的研究开发以及设计生产，LAYERTEC的飞秒镜片性能品质不仅十分***，在功能方面也多种多样。

深圳维尔克斯光电是LAYERTEC中国供应商，***代理其公司的所有型号系列。光学镜片应用波长范围从VUV（157nm）到NIR（4m）。

字数限制型号未全，如需咨询更多型号 请联系维尔克斯的销售经理。

LAYERTEC主要产品包括:各种波长的纳秒、皮秒、飞秒、连续激光反射镜，以及研究应用的激光滤光片，多功能宽带镜，负色散镜，GT干涉镜等

NanosecondLaserOptics、Picosecond Laser Optics、Femtosecond Laser Optics

cw and ns Laser Optics、Low Loss Laser Optics、Multipurpose Broadband Mirrors

Metallic Mirrors、 Filters for Laser Applications、Uncoated Optics

主要优点是：高透反率、低损耗和高损伤阈值。

一、纳秒激光反射镜 Nanosecond Laser Optics

常规激光光学元件按照其工作波长划分，主要包含以下几类：

·F2激光光学元件·ArF激光光学元件·KrF，XeCl和XeF激光光学元件

·红宝石激光和其它宝石激光光学元件·纳秒钛蓝宝石激光光学元件

·半导体激光光学元件·掺Yb激光光学元件

·掺Nd激光光光学元件·掺Nd和掺Yb激光二次谐波应用光学元件

·掺Nd和掺Yb激光三次谐波应用光学元件

·掺Nd和掺Yb激光高次谐波应用光学元件·掺Nd激光线光学元件

·掺Ho和掺Tm激光光学元件·掺Er激光以及3um波段光学元件

负色散镜:

此反射镜具有负分散特性，可用于压缩飞秒激光的脉宽。 和传统的飞秒激光脉宽压缩棱镜相比，此种反射镜更小巧，光损失也更小。中心波长针对钛：蓝宝石激光设计，为800nm。可提供用于共振腔的平面镜和凹面镜。

LAYTERTEC的负色散镜具有非常高的反射率(R=99.8% >99.9%)，因此可以提高反射次数来达到补偿效果，反射次数可达1020次。

二、皮秒激光反射镜 Picosecond Laser Optics

HR(0°,343nm)>99.7% + R(0°,515+1030nm)<1% (ps-pulses)

HR(0°, 515nm)>99.9% (high power)

HR(0°,532nm)>99.9% (High Power)

HR(0°,750-850nm)>99.9% (high power for ps-pulses)

HR(0°,970-1090nm)>99.9% (High Power for ps-Pulses)

HRr(0-20°,970-1090nm)>99.95% (high power)

HR(0°, 980-1090nm)>99.98% (High Power für ps-Pulse)

HR(0°,990-1070nm)>99.98% (High Power für ps-Pulse)

HR(0-10°, 1030±30nm)>99.98% (High Power ps-Pulse)

HR(0°,1000-1100nm)>99.98% (High Power für ps-Pulse)

HR(0°,1030nm)>99.98% (High Power)

HR(0°,1030±30nm)>99.98% (High Power for ps-Pulses)

HRr(0-20°,970-1090nm)>99.95% (high power for ps-pulses)

HR(0°,1030-1064nm)>99.9% (High Power)

HR(0°,1064nm)>99.98% (High Power für ps-Pulse)

HRr(22.5°,1010-1070nm)>99.9% (High Power)

Ag + Multilayer, HRr(0-45°, 1020-1040nm)>99.9%

HRr(45°,213nm)>95% (HRs(45°,208-218nm)>97%, HRp(45°,213nm)>93%) (fluoridisch)

HRs(45°,343nm)>99.9% + HRp(45°,343nm)>99.7%

HRp(45°, 355nm)>99.0% + Rs(45°, 532nm)<3% + rp(45°, 1064nm)<2%

HRp(45°, 355nm)>99.5% + Rs(45°, 532nm)<5% + rp(45°, 1064nm)<5%

HRr(45°, 515nm)>99.9% (High Power for ps-pulses), T>0.05%

HRs,p(45°,515nm)>99.9% (High Power für ps)

HRs,p(45°,515nm)>99.9% + Rs,p(45°,1030nm)<2%

HR(0°, 600-700nm±6nm)>99.9%, GVD<20fs2

both mirrors: HR(0°, 600-900nm)>99.8%, GVD (600-900nm)~ -45fs2±20fs2, (GVD-Oscillation compensated, see data sheet)

HR(0°, 600-930nm)>99.9%, GVD(700-950nm)~ -65±20fs2 (GVD-Oszillation compensated)

HR(0°, 600-980nm)>99.9%, GVD(700-880nm)~-100fs2...+40fs2

HR(0°, 610-1030nm±10nm)>99.8%

HR(0°, 620-720nm±5nm)>99.9%

HR(0°, 620-900±8nm)>99.9%, GVD(700-900nm)~ -65±20fs2(GVD oscillation compensated)

HR(0-12°, 620-1000±7nm)>99.8%, GVD(680-900nm)~-60±20fs2

HR(0°, 620-1000nm)>99.85%, GDD(0°, 700-1000nm)~ -50±20fs2, GDD - osz. compensated

HR(0°, 620-1050nm)>=99.9% + R(0°, 490-540nm)<5%, gdd(680-1020nm)~ -50+/-20fs2, (gdd-oszillation compensated)

HR(0°,620-1080nm)>99.9% + R(0°,488-532nm)<5%

HR(0°, 620-1120±10nm)>99.9%, GD optimized

HR(0°, 630-980nm)>99.7% + R(0°, 515-545nm)<10%, gdd(700-1020nm)~ -70+/-30fs2, (gdd-oszillation compensated)

HR(0°, 630-1100±8nm)>99.8% + R(0°, 480-540nm)<10%

HR(0°, 630-1140+/-10nm)>99.85%, GVD~-200fs2....100fs2

HR(0°, 630-1200nm)>99.8%, |GDD-R(0°, 650-1150nm)|<400fs2

HR(0°,640-1000nm)>99.8% + R(0°,(510-545)±5nm)<15%, gdd(720-1000nm)~ -70±30fs2, (gdd-oscillation compensated)

HR(0°, 630-1000nm)>99.8% + R(0°, 510-550nm)<10%, gvd(720-1020nm)~ -70±30fs2

HR(0°, 640-1080+/-8nm)>99.9% + R(0°, 490-540+/-5nm)<5%, gvd~ -200...+100fs2 (gvd optimized for opo-application)

HR(0°, 650-860±7nm)>99.9%, GVD(770-795nm)~-550±75fs2

HR(0°, 650-900±5nm)>99.9%, GVD(700-900nm)~ -100±30fs2 , (GVD-oszillation compensated)

HR(0°, 650-900±8nm)>99.9%, GVD~-150fs2....0fs2, with smoothed GD

HR(0°, 650-1100nm)>99.8%, GD optimized

HR(0°, 650-1070±8nm)>99.9%, GVD(740-980nm)=-70±30fs2

HR(0°,650-1100nm)>99.8% + R(0°,488-532nm)<5%

HR(0°,660-980nm±10nm)>99.7% + R(0°,500-550nm)<5%, gvd~-50±20fs2(730-1000±10nm)

HR(0°, 660-1050nm)>99.9%, High Power optimized (780-850nm)

booth mirrors HR(0°, 660-1060nm)>99.8%, GDD(730-970nm)= -70±20fs2, (GDD-Oszillation compensated)

HR(0°, 660-1100±9nm)>99.8%, GVD(740-1010nm)=-70±20fs2

HR(0°,660-1130nm±10nm)>99.9%, GVD(780-1010nm)~ -120fs2...+40fs2

HR(0°, 660-1130+/-8nm)>99.9% + R(0°, 510-550+/-5nm)<5%, gvd~ -200...0fs2 (gvd optimized for opo-application)

HR(0°,660-1150nm)>99.9% + R(0°,480-560nm)<5%

HR(0°,670-1000nm)>99.8%, GVD(700-970nm)=-60±20fs2

HR(0-5°, 670-1020nm)>99.8%, GDD Osz. compens. (0-5°, 730-850nm) ~-500...+750±100fs2, TOD opt.

HR(0-5°, 670-1040nm)>99.8%, GDD Osz. compens. (0-5°, 770-990nm) ~-120±30fs2

HR(0°, 680-890±7nm)>99.8%, GVD (0°, 720-880nm)~+100±30fs2

HR(0°, 680-890±7nm)>99.8%, GVD (0°, 720-880nm)~+80±30fs2

HR(0°,680-1100nm)>99.8%, not GVD optimized

HR(0°,680-1100nm)>99.8% + HT(0°,488-532nm)>90%

HR(0°,690-820nm)>99.9% + R(0°,488-532nm)<5%, gvd<20fs2

HR(0°,690-880nm±10nm )>99.9% + R(0°,500-550nm)<2%, gvd<20fs2 (710-870±10nm)

HR(0°, 690-890±5nm)>99.9% + R(0°, 532nm)<2%, gdd(0°, 700-880±10nm)~0fs2

HR(0°,690-960nm±10nm)>99.9% + R(0°,500-540nm)<5%, gdd~0fs2(690-880±10nm)

HR(0°,700-840nm)>99.95%, GVD<20fs2

HR(0°, 700-850nm)>99.8% + HT(0°, 514-532nm)>95%, GVD~0fs2

HR(0°,700-870±7nm)>99.9%, |GDD|<40fs2

HR(0°, 700-870±8nm)>99.9%, GDD=-40±15fs2(725-880nm)

HR(0°, 700-880±8nm)>99.9% + R(0°, 450-550nm)<2%, gvd<20fs2 (710-870±8nm)

HRr(0-45°,700-890±10nm)>99.9% (not GVD-optimized)

HR(0°,700-900nm)>99.8%, GDD<40fs2

HR(0°,700-900nm)>99.9%, GVD(700-900)~ -50±20fs2 (GVD-oscillation compensated)

HR(0°, 700-900nm)>99.9%, GVD(780-805nm)~-550±50fs2

HR(0°,700-900nm)>99.9%, GVD<40fs2

HR(0°,700-900nm)>99.8% + R(0°,532nm)<2%, gdd~0fs2

HR(0°, 700-950±5nm)>99.9% + R(0°, 505-535nm)<10%, gvd~ -50±20fs2(680-940±5nm)

HR(0°, 700-970nm)>99.85%, GDD(700-950nm)~ -60....-30fs2 (GDD - oscillation compensated and TOD optimized)

HR(0°,700-980nm)>99.9% + R(0°,510-532nm)<10%, igdd(r,0°,710-870nm)i<30fs2

HR(0°,700-1000nm)>99.9%, GDD-R(0°,700-1000nm)=-50±50fs2

HR(0°,700-1030nm)>99.8%, GVD(730-1000nm)=-60±20fs2

HR(0°, 705-920±8nm)>99.9%, GVD~-40±15fs2

HR(0°, 710-850±8nm)>99.9% + R(0°,350-400±5nm)<3%

HR(0°,710-860nm)>99.9% + R(0°,480-570nm)<2%, gvd<20fs2

HR(0°, 710-880±5nm)>99.9%, GDD<20fs2

HR(0°, 710-890±8nm)>99.9% + R(0°,480-550±5nm)<3%, gvd<20fs2

HR(0°, 710-900±8nm)>99.9% + R(0°, 510-550nm)<5%, gvd=-40±10fs2

HR(0°, 710-940±8nm)>99.9%, GVD(0-12°, 740-870nm)~-350fs2....+350fs2, increasing arithmetically

HR(0°, 710-950±8nm)>99.9% + R(0°, 500-550nm)<2%, gvd(0-12°, 700-1000nm)~0...-300fs2

HR(0°, 715-820nm)>99.9%, GDD<20fs2

HR(0°,720-870nm)>99.9%, |GVD|<20fs2

HR(0°, 720-880nm)>99.9%, GVD(0°, 760-840nm)~+150fs2....-100fs2 (linear decreasing)

HR(0-12°, 720-880±8nm)>99.9%, GVD~-40±10fs2

HR(0°,720-880nm)>99.***, GDD(0°,720-880nm)~ -10±10fs2

HR(0°,720-880±8nm)>9.9% + R(0°,514-532nm)<5%, gvd=-40±10fs2

HR(0°, 720-920nm)>99.9%, GVD(790-815nm)~ -550±50fs2

HR(0°,720-920nm)>99.8% + R(0°,532nm)<5%, gdd~0fs2 (730-900nm)

HR(0°,720-940±5nm)>99.9% + R(0°,520-560nm)<5%, gvd=-40±10fs2

HR(0°,720-1210+/-10nm)>99.9%, GD~0-100fs

HR(0°,725-930±5nm)>99.9%, GVD (735-910nm)<20fs2

HR(0°,730-860±8nm)>99.9% + R(0°,500-550nm)<3%, gvd<20fs2

HR(0°, 730-870nm)>99.8%, GVD(0°, 630-890nm)~-40fs2±15fs2 , (GVD-oszillation compensated)

HR(6°, 730-870nm)>99.8%, GDD=115±35fs2

HR(0°,730-880±10nm)>99.9%, GVD<20fs2

HR(0°,730-890±7nm)>99.9%, GVD<20fs2

HR(0°,730-900nm±10nm)>99.8% + R(0°,532nm)<5%, gvd~-50±10fs2(750-920nm)

HR(0°, 730-1030±5nm)>99.8% + R(0°, 650-690nm)<5%, gvd~-50±40fs2( 750-920nm)

HR(0°, 740-840nm)>99.9%, |GDD-R(0°, 740-840nm)|<20fs2

HR(0°,740-840nm)>99.75% + GDD(0°,750-830nm)~450(±150)fs2

HR(0°,740-860nm)>99.9%, GDD<50fs2

HR(0°,740-860nm)>99.9%, GVD<20fs2

HR(0°,740-910nm)>99.8%, GDD(0°,750-910nm)~ -45±10fs2

HR(0°,740-950±5nm)>99.9%, GDD (760-930nm)<20fs2

HR(0°,750-850nm)>99.9% + R(0°,532nm)<1%

HR(0°, 750-850nm)>99.9% + R(0°, 532nm)<3%, gdd-r(0°, 750-840±5nm)=-120±40fs2

HR(0°,750-850nm)>99.9% + R(0°,670nm)<5%

HR(0°,750-850nm)>99.9%, |GDD|<20fs2

HRs,p(0-20°,750-850nm)>99.9%, |GDD|<20fs2

HR(0°, 750-870±8nm)>99.9% + R(0°, 360-480nm)<5%

HR(0°, 750-900nm)>99.9%, /GDD/~ -45±10fs2

HR(0°,750-920nm)>99.9% + R(0°,520-580nm)<2%, gvd<20fs2

HR(0°,750-920nm)>99.9%, GDD<20fs2

HR(0°,750-930nm)>99.9%, GVD<20fs2

HR(0°,750-1250nm)>99.9%

HR(0°,760-860nm)>99.9% + R(0°,380-430nm)<5%, gvd<20fs2

HR(0°, 760-930±8nm)>99.95%, GVD~-20±10fs2(0°, 740-860nm)

HRp(0-10°, 770-830nm)>99.9%, GDDp(0-10°, 770-830nm)~-150±30fs2

HR(0°,770-940+/-8nm)>99.9% + R(0°,490-550nm)<5%, gvd(0°,770-940nm)<20fs2

HR(0°,770-970nm)>99.9%, GDD<40fs2

HR(0°,780-900±8nm)>99.9% + R(0°, 390-420±4nm)<3%, gvd<20fs2

HR(0°,780-940nm)>99.9%, GVD<20fs2

HR(0°,800-880nm)>99.9% + R(0°,532nm)<2%, gvd<20fs2

HR(0°,800-900nm)>99.9% (High Power)

HR(0°,800-900nm)>99.9%, GVD<20fs2

HR(0°,800-900nm)>99.9% + R(0°,685nm)<2%, gvd<20fs2 (high power)

HR(0°,820nm)>99.9%

HR(0°, 830-950±8nm)>99.9%, GVD<20fs2

HR(0°,840-920nm)>99.9% + R(0°,410-470nm)<10%, |gdd-r(0°, 840-920nm)|<20fs2

HR(0°,840-920nm)>99.9% + R(0°,410-470nm)<5%, gvd<20fs2

HR(0°, 840-1050nm)>99.9%, GVD(890-980nm)~-65±15fs2

HR(0°, 870-1180±10nm)>99.9%, GVD(0-10°, 1064nm)~ -1000±100fs2

HR(0°,900-1000nm)>99.9%

HR(0-10°, 900-1000nm)>99.95% + R(0-10°, 450-500nm)<5%

HR(0-10°, 900-1100±10nm)>99.8%, GVD(1040-1090nm)~-550±100fs2

HR(0-3°, 900-1100±10nm)>99.9%, GVD(1028±10nm)~-550+50/-75 fs2

HR(0°,900-1100±10nm)>99.9%, GDD<20fs2

HR(0-12°, 900-1120nm±10nm)>99.9%, GVD(0-12°, 1030-1040±5nm)~ -450±50fs2

HR(0°, 920-1140±10nm)>99.9%, GVD(990-1050nm)~ -250±50fs2

HR(0°, 930-1130nm±10nm)>99.9%, GVD(1020-1070±5nm)~ -375±50fs2

HR(0°, 930-1140±9nm)>99.9% with Rmin~99.7% at 1033±5nm (see data sheet), GVD (990-1110±5nm) ~ -100fs2±20fs2

HR(0°, 940-1090±10nm)>99.9%, GVD(1000-1065±5nm)~-100fs2±20fs2

HR(0°,940-1100nm)>99.9%, GDD<20fs2

HR(0-10°,940-1100nm)>99.9%, GVD(1020nm)~ -320±50fs2, GVD(1060nm)~ -250±50fs2

HR(0-10°, 940-1110nm±10nm)>99.9%, GVD(0-10°,1010-1080nm)~ -250±50fs2

HR(0-10°, 940-1110nm±10nm)>99.9%, GVD(0-10°,1020-1030nm)~-1300±150fs2

HR(0°, 940-1180±5nm)>99.9%, GVD(990-1120nm)~ -55±10fs2

HRp(0-10°, 940-1140±10nm)>99.9%, GVDp(0-10°,1035±10nm)~+1000±200fs2

HR(0°, 940-1140±10nm)>99.9%, GVD(980-1130±5nm)~ -100fs2±20fs2

HR(0°,940-1150nm)>99.9%, GVD(0°,930-1150nm)~ -55±15fs2

HR(0-10°,950-1120±10nm)>99.9%, GVD(0-10°,1030nm)~ -550±50fs2

HR(0-15°,950-1120±10nm)>99.9, GVD(0-10°,1040nm)~ -550±50fs2

HR(0°,950-1130±10nm)>99.8±0.5%, GVD(0°,1030nm)~ -1200±50fs2

HR(0-10°, 950-1150±10nm)>99.9%, GVD(0-10°, 1030-1040nm)~ -550±50 fs2

HR(0-15°, 950-1140±10nm)>99.9%, GDD(1030-1040nm)~ -550±50 fs2

HR(0-10°, 950-1170nm±10nm)>99.9%, GVD(0°, 1000-1080nm)~ -250±75fs2

HR(0-12°, 950-1200nm±10nm)>99.9%, GVD(0-12°, 1030nm)~ -250±50fs2

HR(0°,1040nm)~99.85...99.9%, GVD(0°,1020-1035nm)~-1300±150fs2

HR(0°,1040nm)~99.85...99.9%, GVD(0°,1025-1045nm)~ -1300±150fs2

HR(0°,1040nm)~99.85...99.9%, GVD(0°,1035-1050nm)~-1300±150fs2

HR(0°, 960-1140±10nm)>99.9%, GVD(0°, 1030nm)~-1300±200fs2

HR(0°, 960-1200nm±10nm)>99.9%, GVD(1020-1080±5nm)~ -200±50fs2

HR(0-10°, 960-1220nm±10nm)>99.9%, GVD(0-10°, 1020 - 1080nm)~ -250±75fs2

HR(0-3°, 970-1100±10nm)>99.95%, GVD(1030nm)~-800±75fs2, GVD(1060nm)~0fs2, for TOD-management

HR(0°, 970-1120nm)>99.9%, GDD(0-10°,1040nm)~ -1300±150fs2

HR(0-10°, 970-1170±10nm)>99.9%, GVD(0-10°,1005-1025nm)~-950±125fs2

HR(0-14°, 970-1170±10nm)>99.9%, GVD (0-14°, 1045nm) ~ -1200±100fs2

HR(0-10°,970-1200±7nm)>99.9%, GVD(0-10°,1064nm)~-650±100fs2

HR(0-10°, 970-1250nm±10nm)>99.9%, GVD(0-10°,1025-1100nm)~-250±50fs2

HR(0-12°, 976nm)>99.9% + R(0-12°, 488nm)<5%

HR(0-10°, 980-1110nm±10nm)>99.85%, GDD(0-10°, 1030nm)~ -900±100fs2

HR(0-10°,980-1120nm)>99.9%, GDD(0-10°,1020-1080nm)~ -300±50fs2

HR(5°, 980-1130nm)>99.7%, GVD(1035nm)~+1800±100fs2

HR(0°,980-1150±10nm)>99.9%, GVD(0°,1040-1070nm)~ -500±50fs2

HR(0-10°,980-1150±10nm)>99.8%, GVD(0°/10°,1042nm/1036nm)~ -550±50fs2

HR(0-10°, 980-1170nm)>99.8%, GVD(1010nm)~-600±50fs2, GVD(1080nm)~-350±50fs2

HR(0°, 980-1460±10nm)>99.8%, GVD(1000-1500nm)~ -120±40fs2 , (GVD-Oszillation compensated)

HR(0-5°, 990-1060±10nm)>99.6%, GVD(0-5°, 990-1060nm)~-600....-350fs2

HR(0-10°, 990-1130nm)>99.9%, GDD(0-10°,1030nm)~ -900±100fs2

HR(0-10°, 990-1180nm)>99.9%, GVD(1045±10nm)~ -800±100fs2

HR(0-10°, 990-1250nm±10nm)>99.9%, GVD(0°,1030-1090nm)~-250±50fs2

HR(0-10°,1000-1130±8nm)>99.9%, GVD(0-10°,1030nm)~ -1000±100fs2

HR(0-12°, 1000-1160±9nm)>99.9%, GVD(0-12°,1064nm)~ -1000+100-200fs2

HR(0-10°,1000-1230nm)>99.9%, GVD(0°,1100-1140nm)~-500fs2±50fs2

HR(0°,1000-1450nm±15nm)>99.75% + R(0°,680-930nm)<10%

HR(0°, 1000-1600±10nm)>99.8% + R(0°, 700-950nm)<10%, gvd~-300....0fs2 (gvd optimized for opo-application)

HR(0°,1010-1064nm)>99.9% + R(0°,935-980nm)>***

HR(0°,1010-1070nm)>99.9% (High Power)

HR(0°,1020-1060nm)>99.9%, |GDD|<20fs2

HR(0°,1020-1080nm)>99.9%, |GDD|<20fs2

HR(0°, 1020-1650±10nm)~99.9%, GVD~ -200fs2 at 1080nm...0fs2 at 1650nm (GVD optimized for OPO-application)

HR(6°,1030nm)>99.9%, GDD(6°,1030nm)~ -10 000fs2 (+3000/-8000fs2)

HR(0°, 1030nm)>99.95%, GVD(0-4°,1030nm)~ -1300±150fs2

HR(0°, 1030nm)>99.98%, GDD-R(0°,1030nm)~(-550±50)fs2

HRs(8°,1030-1045nm)>99.95%, GDD(8°, Rs,1030-1045nm)= -1200±200fs2

HR(0-10°,1040-1042nm)>99.9%, GDD(0-10°, 1040-1042nm)=-10000 +/-2500 fs2

HR(0-10°,1047nm)~99.93...99.94%, GVD(0-10°,1047nm)~ -1000±150fs2

HR(0°,1050-1064nm)>99.9%, GDD(0-12°,1050-1064nm)~ -1300±150fs2

HR(0°,1050-1200nm)>99.9% + R(0°,740-830nm)<5%, gvd<20fs2

HR(0-10°,1050-1290nm)>99.9%, GVD(0°,1090-1180nm)~ -200fs2±50fs2

HR(0-10°,1050-1300nm)>99.9%, GVD(0°,1090-1160nm)~ -350fs2±50fs2

HR(0°, 1060-1600nm)>99.8%, GDD~ -150±100fs2 (GDD optimised for OPO-application)

HR(0°,1064nm)>99.9% + R(0°,532+808nm)<5%

HR(0°,1090-1400nm±15nm)>99.9%, GVD(1170-1380±15nm)~-150±25fs2

HR(0°,1120-1420nm±10nm)>99.9% + R(0°,1030nm)<10%, gvd~ -70±20fs2(1150-1380nm±10nm)

HR(0°,1130-1420nm±15nm)>99.9%, GVD(1200-1300±15nm)~-250±75fs2

HR(0°,1170-1470nm±5nm)>99.8% + R(0°,1040-1090nm±5nm)<10%, gvd~-60±10fs2(1200-1400nm±10nm)

HR(0°,1290-1650nm±20nm)>99.9% + R(0°, 1050-1100nm)<5%, gvd~ -150...0fs2(1350-1600nm)

HR(0°,1300-1350nm)>99.9% + HR(0°,1325±10nm)>99.95% (High Power)

HR(0°,1375-1575nm)=99.8±0.05%, GDD<30fs2

HR(0-10°,1400-1700nm)>99.85%, GVD(0-10°,1480-1530nm)~ -500fs2±50fs2

HR(0°, 1400-1800nm)>99.8% + R(0°, 1000-1100nm)<3%, gvd (0°, 1400-1800nm)~0....-400fs2, optimized for opo - application

HR(0°,1420-1720nm)>99.9% + R(0°,870-1050nm)<2%, |gdd|<40fs2 (1440-1700nm)

HR(0°, 1450-1700±10nm)>99.9% + R(0°, 950-1000nm)<3%, gvd (0°, 1500-1700±10nm)~-120fs2, optimized for opo - application

HR(0°,1550-1615nm)>99.***, T(0°,1580nm)~0.002% (Low Loss)

HR(0°, 1600-1700nm)>99.*** low loss, T (0°, 1650nm)~0.0008%, single stack like

HR(0°,1800-2075±20nm)>99.9% + R(0°, 808 + 980nm)<2%

HR(0°,1850-2200nm)>99.9%

HR(0°, 3300nm)>99.9%, GDD(0°, 3300nm)<20fs2, single stack like

HR(0°, 840-1160±10nm)>99.9%, GVD(0-10°, 1040nm)~ -1000±100fs2

HRs(30°,210-225nm)>97% + Rs(30°,410-450nm)<5% (fluoridic)

HRs(0-22.5°,390nm)>99.9% + PRs(0-22.5°,700nm)=20±2%

HRs+p(22.5°,405nm)>99.9% + Rs+p(22.5°,810nm)<5%, gvd<20fs2

HRs(12°,1030nm)>99.9%, GVDs(12°,1030nm)~ -1300±200fs2

HRs(30°,1370-1750±5nm)>99.9%, GVDs(1600nm)~ -250fs2

HRs(30°,1480-1680±15nm)>99.9%, GVDs(1590nm)~ -550fs2

HRs(30°,1520-1740±15nm)>99.9%, GVDs(1580nm)~ -100fs2

HRs(30°,2.25-2.6μm)>99.5%+ Rs(30°,1064nm)<1%

HRr(45°,200nm)>95% (fluoridic)

HRr(45°,205nm)>95% + Rs(45°,410nm)<10%

HRr(45°,210nm)>95% (HRs(45°,205-215nm)>97%, HRp(45°,210nm)>93%) + Rp(45°,840nm)<2% (fluoridic)

HRs(45°, 210-235nm)~90% + Rp(45°, 300-1000nm)<8%, |gdd-rs(45°, 210-235nm)| optimised

HRp(45°,252-268nm)>99.0%

HRr(45°,266nm)>99.5%

HRr(45°,270nm)>*** + Rr(45°,405+810nm)<10%

HRr(45°,266nm)>99.6%

HRs,p(45°,266nm)>98% + HRs,p(45°,400+800nm)>***, GDD-optimiert

HRr(45°,270nm)>99.5%

HRr(45°,270nm)>99.6%

HRr(45°,270+405nm)>***

HRs(45°,270-310nm)>*** + Rs+p(45°,390-430nm)<3%

HRr(45°,280nm)>99.5%

HRp(45°,280nm)>98% + Rp(45°,420+840nm)<3%

HRs(45°, 280-330nm)>99.5% + Rp(45°, 440-770nm)<1%, |gdd-rs(45°, 280-330nm)|<20fs2, |gdd-rp(45°, 285-330nm)|<20fs2, |gdd-ts,p(45°, 440-770nm)|<10fs2

HR(0°, 285nm)>99.8% Low Loss, T(0°, 285nm)~0.03%

HRr(45°,285nm)>99.7%
